| Model No. | Dimensions | Max. No. Cylinders | Weight |
| CH040 (CH040YP) | 33"W x 40"D x 40"H | 4 | 170 lbs. |
| CH080 (CH080YP) | 33"W x 40"D x 71"H | 8 | 280 lbs. |
| CH120 (CH120YP) | 50"W x 40"D x 71"H | 12 | 384 lbs. |
| CH160 (CH160YP) | 64"W x 40"D x 71"H | 16 | 516 lbs. |
- Stores forklift propane cylinders on their sides.
- Lockable mesh door(s) with slide bolt hasp, lock not included.
- All welded, ready to use, meets OSHA 1910.
- 13-gauge flattened mesh sides.
- 14-gauge solid top.
- 1-1/2" x 3/16" thick corner angles.
- Foot pads with pre-drilled holes.
- Powder coated safety yellow.
- Safety signage in large red letters.
- Smooth 1" tube support rails for cylinder protection.
- Holds 20-43 lb. Horizontal Cylinders.
Weights & Dimensions
| Width | 50 in |
| Height | 71 in |
| Length | 40 in |
| Weight | 444 lbs |
Online shipping quotes for orders over 8 pieces are likely incorrect and invalid. Please call for a quote.
